Portkeys PT5 II 5 Inch, 4K, HDMI, IPS, FHD, Touchscreen Monitor, 3D LUT Support, 500 Nits

229,90 €

On Order - Ships in 5–7 working days

Description :

The Portkeys PT5 II is an entry-level and very affordable 5-inch Wide Color Gamut touchscreen on-camera monitor.

This HDMI-only monitor has a maximum brightness of 500nits and can be powered for hours by Sony NP-F or Canon LP-E6 batteries.

Ready for your next creative adventures, the compact and rugged design houses a complete set of professional monitoring tools


Key features:


5-inch, 10-bit panel with a resolution of 1920 x 1080 and a 1000:1 contrast ratio.

Maximum brightness of 500nits.

1 x HDMI input, 1 x HDMI output, 1 x 3.5mm audio output.

Maximum input/output resolutions: 4K DCI at 24p or 4K UHD at 30p.

Professional monitoring tools: Waveform, Histogram, Vectorscope, Peaking, False Color.

3D LUT monitoring. Monitoring tools can be set before or after the 3D LUT.

The dual battery plate accepts Sony NP-F or Canon LP-E6 batteries.

5.5mm barrel connector 7.4V-24V power input. 5V USB-A power input.

Low power draw: only 7W.

Lightweight and rugged aluminum housing: only 150g/5.29oz.


Specifications :




Display :
Panel Type – IPS-Type LCD
Display Size – 5.0″ / 12.7 cm
Resolution – 1920 x 1080
Aspect Ratio – 16:9
Viewing Angle – Horizontal: 178°
Vertical: – 178°
Touchscreen – Yes
Maximum Brightness – 500 nits / cd/m2
Contrast Ratio – 1000:1
Bit Depth / Color Support – 8-Bit+FRC (1.07 Billion Colors)
HDR Compatibility – None
Pixels Per Inch (ppi) 441 ppi
Real-Time LUT Monitoring – SDR
Image Controls – Anamorphic De-Squeeze, Check Field, Color Temperature Selection, False Color, Focus Peaking, Histogram, Image Flip, Pixel Zoom, R/G/B/Chroma Only, Screen Markers, Underscan, Vectorscope, Waveform, Zebra
Video I/O – 1 x HDMI Input , 1 x HDMI Output
Embedded Audio – HDMI
Audio I/O – 1 x 1/8″ / 3.5 mm Headphone Output
Built-In Speaker – None
Power I/O – 1 x Barrel (24 VDC) Input
Other I/O – 1 x USB-A Input / Output
Media/Memory Card Slot – None
Wi-Fi – None
Format Support :
Video Format – HDMI
DCI 4K: 24
UHD 4K: 30/29.97/25/24/23.98
1080p: 60/59.94/50/30/29.97/25/24/23.98
1080PsF: 30/29.97/25/24/23.98
1080i: 60/59.94/50
720p: 60/59.94/50
576p: 50
576i: 50
480p: 60/59.94/50
480i: 60/59.94/50
Power :
DC Input Power – 7 to 24 VDC
Battery Type – 1 x LP-E6 or L-Series
Power Consumption – 7 W
General :
Material of Construction – Plastic
Dimensions – 5.4 x 2.8 x 0.7″ / 136 x 72 x 17 mm
Weight – 4.6 oz / 130 g



Weight1,5 kg
